Redefining Outdoor Cooking Stand Manufacturing with Precision and Power

In the booming outdoor gear market, outdoor cooking stands have gained immense popularity for their portability and practicality. At the heart of their production lies one crucial process — wire bending. And when it comes to precision, efficiency, and reliability, the wire bending machines from Jinchun Industrial are becoming the go-to solution for outdoor cooking stand manufacturers.

Engineered specifically for the unique needs of outdoor stove racks and cooking stand production, the Jinchun 2D CNC wire bending machine delivers outstanding performance across the board. Capable of producing 8–10 units per minute, it significantly boosts throughput, making it the ideal choice for companies looking to scale production during peak order seasons.

Built to Handle Diverse Materials and Sizes

As a leader among small 2D CNC iron wire bending machine manufacturers, Jinchun has developed a system that handles a wide range of materials, especially iron wires commonly used in outdoor cooking frame components. With wire diameter support from 4mm to 10mm and product dimensions up to 800 x 600mm, this ring making and forming machine effortlessly bends everything from compact structural parts to large, load-bearing frame elements.

Technical Powerhouse for High-Precision Tasks

This wire bender and welder is built with power and precision in mind. Running on a 3-phase 380V + ground line setup, it guarantees stable operation even under demanding conditions. The machine features:

28 Cr12 straightening wheels to ensure excellent wire linearity

High-grade SKD11/51 bending molds with 50–52° hardness

4 Cr12 polished feeding wheels heat-treated to 58° for maximum wear resistance

4-axis control system powered by high-performance servo motors including:

4.5kW feeding servo

2.3kW bending servo

2.3kW cutting servo

Total system power: approx. 10.1kW

This robust mechanical setup ensures the machine delivers top-tier accuracy and durability, perfect for high-demand wire forming and welding tasks.

Smart Design for Seamless Operation

The Jinchun 2D wire bending machine doesn’t just bend — it thinks. With storage capacity for 4,000 data sets (each consisting of up to 300 motion commands), it allows for quick program switching based on varying product needs. Its smart features include:

Max wire feed speed: 27m/min

Max external bending speed: 50 bends/min

Bending angle range: ±360°

Bending and feeding accuracy: ±0.5mm

These specifications make it one of the most flexible and accurate machines on the market for ring making, iron wire forming, and welding in the outdoor product sector.

Proven Results in the Field

Jinchun's 2D CNC wire benders have already helped numerous clients deliver complex, high-volume projects with speed and precision. Whether producing intricate bend patterns or handling bulk orders, the machine consistently delivers top-quality results — earning high praise from industry leaders.

Why Choose Jinchun Industrial?

Choosing Jinchun means choosing efficiency, accuracy, and industrial-grade quality. This machine doesn’t just meet the demands of modern outdoor cooking stand production — it anticipates them. As a trusted name among small 2D CNC iron wire bending machine manufacturers, Jinchun’s commitment to intelligent automation continues to push the boundaries of what’s possible in wire processing.

Unlock new levels of performance and stand out in a competitive outdoor gear market — let Jinchun’s advanced wire bending technology lead the way to your next manufacturing breakthrough.
