Spot Welding Machine
Jinchun Automatic Customizable Control High Speed Spot Welding Machine for Industrial Automation Aluminum Casting Machine
Product Description
Product Overview
The spot welding and projection welding of carbon steel plates and stainless steel plates are widely used in industries such as high carbon steel saw blades, wire products, electrical terminals, automotive components, stainless steel products, low-voltage electrical appliances, hardware lighting fixtures, kitchenware and utensils, small household appliances, and small hardware items. Spot welding machines are extensively employed in sectors including wire products, hardware lighting fixtures, kitchenware manufacturing, automotive production, small household appliances, and small hardware components.
SPECIFICATIONS
| Item | Data | Item | Data |
| Machine size | L*W*H 1370(Optional)*560*1780mm | Wire material | Iron, rebar, stainless steel, low or high carbon steel, copper... |
| Machine weight | 430KG | Max welding power | Depend on transformer and arm length |
| Arm length choice | 350mm 450mm 650mm (customize) | Input voltage | 380V2N50HZ |
| Equipment color | White and blue | Duty cycle | 25% |
| Equipment power | 100kva | Second empty voltage | 10V |
| Work environment | 1.No strong acid, alkali and corrosiveness 2. Non-open space | Max electrode distance | 60mm |
| Rated Capacity(KVA) | 100 | Rated welding thickness mm | 4.0+4.0 |
| Rated load duration% | 20 | Max welding thickness(mm) | 5.0+5.0 |
| Rated frequency Hz | 50 | Electrode max pressure | >500 |
| Upper electrode working stroke(mm) | 50/100 | Cooling water consumption(Liter/h) | 600 |
Key Technical Parameters:
Automatic Spot Welding Machine
The top electrode uses pneumatic technology. It is more convenience and precious than traditional welding machine.
Several welding spots can be completed by it at the same time.
The twice conductor takes upper insulation measures. So the performance of insulator will be more stable and reliable than tradition welding machine.
Touch screen automatic control --- You don't need to control it all the time in the flesh just press button or touch screen. The welding operation will be working in 3-5 seconds.
Major loop takes large power controlling silicon component measures, which mean the output power is more powerful,stable and reliable than last generation machine.
If you want to produce stainless steel fry basket, pet cage, barbecue metal net..etc, the machine can not miss it.
What product shapes are compatible with this machine?
Product Qualification
 |
 |
Deliver, Shipping And Serving
Professional ODM&OEM Lash Glue Remover Products Manufacturer for over 20 years. We appreciate cooperation with you.
 |
 |
FAQ
Q1. Why choose us?
A. Our founding team has more than 20 years of experience in the R&D and manufacturing industry of metal forming and welding machinery. What we offer is a good product at a reasonably price.
Q2. Can I customize the product?
A. Yes . We can customize production equipment solutions according to your product requirements .
Q3. Can I get a sample?
A. Yes. But the proofing cost and shipping are negotiated by both parties.
Q4. What's the delivery time?
A. The delivery time needs to be determined by both parties through negotiation .
Q5. How do I order from you?
A. Consulting → equipment plan quotation →negotiation→ prototyping →PO/PI→ payment deposit → production → debugging →delivery→further.
